DWC-PVX20WATX

DWC-PVX20WATX A rugged 20MP MEGApix® Flex vandal dome IP camera with four 5MP motorized lenses for flexible 180°/360° views at 30fps. Star-Light Plus™ delivers vivid color in near-darkness, while True WDR and Smart DNR™ ensure clarity in tough lighting. NDAA/TAA compliant, IP67/IK10 rated, and packed with intelligent analytics—ideal for federal, commercial, and critical infrastructure surveillance.
Features
  • Panoramic Coverage: Capture expansive areas with four 5MP lenses delivering seamless 180° or 360° views—ideal for large spaces needing full situational awareness.
  • Ultra-High Resolution: Enjoy 20MP total resolution for detailed surveillance, enabling precise identification and forensic analysis.
  • Motorized Zoom & Autofocus: Each 2.8–8.0mm lens features motorized zoom and autofocus, enabling flexible setup and remote adjustments.
  • Low-Light Performance: Star-Light Plus™ technology ensures vivid color imaging even in near-total darkness, reducing the need for external lighting.
  • True Wide Dynamic Range (WDR): Maintain image clarity in challenging lighting conditions with True WDR, balancing bright and dark areas effectively.
  • Cost-Efficient Installation: Replace multiple single-sensor cameras with one multi-sensor unit, reducing installation complexity and infrastructure costs.
  • Flexible Deployment Options: Supports wall, ceiling, and pendant mounting, offering versatile installation for various environments and layouts.
  • Rugged & Weatherproof Design: IP67 and IK10-rated housing protects against harsh weather and vandalism, ensuring reliable outdoor performance.
  • DW Spectrum® Ready: Fully compatible with DW Spectrum® for intuitive video management, remote access, and scalable deployment.
  • NDAA/TAA Compliance: Meets federal procurement standards, making it suitable for government and critical infrastructure deployments.

Learn about how DW
solutions can work for you

View All Markets

Versatile installation

A single Flex™ camera can replace multiple single-sensor cameras with great ROI. With a variety of lens arrangements and positioning, the camera can enhance any application and cover any area needed with no blind spots.

Magnetic track flexibility

The camera's unique magnetic track allows four individual lens modules to be placed in almost any possible configuration. A fifth, vertical, top view position in the center of the camera offers complete coverage and field of view control.

4x vari-focal lenses with motorized zoom and auto-focus

Adjust the camera’s four (4) individual vari-focal lens modules to achieve the ideal field of view based on your unique needs.

Easy camera installation

The camera includes a simple double-lock mechanizsm between the camera and mounting accessory, making installation quicker, simpler and faster.

Wide tilting angle

Each lens module has a total tilt angle of up to 80°, thanks to the modules' aspherical hemispheric surface. This reduces blind spots in the camera's foreground.

Star-Light Plus™ color in darkness technology

Star-Light Plus™ color in near-total darkness technology provides crisp, clear images in the absence of ambient light.

IVA Intrusion Lines and Detection Zones

MEGApix IVA cameras include Intelligent Video Analytics detection capabilities already activated on the camera and ready for deployment.

Learn More.

IVA Object Detection Zones

The MEGApix IVA offers advanced rules to the IVA Video Content Analysis detection capabilities.

Learn More.

Specifications

Image sensor 5MP 1/2.8" CMOS sensor (x4)
Maximum resolution 20MP
Minimum Scene Illumination in color 0.05 lux (color)
0.1 lux (B/W)
Test Video Output Local video output CVBS 1.0V p-p (75Ω), 4:3 aspect ratio
Total Pixels 2592 (H) × 1944 (V) (x4)
Lens
Focal Length 2.8mm ~ 8.0mm (x4)
Horizontal Field of View (HFOV) 4x 51° ~ 93°
Illumination Distance NA
Lens Type Vari-focal Lens
Vertical Field of View (VFOV) 39°~68° (x4)
I/O
Audio compression G.711
I/O Alarm in/out 1 input
1 output
I/O Audio in/out *Cameras provide a line level audio. The use of amplified microphones and speakers is recommended.
1 input (1.0Vms, 3K ohm)
1 output
Intelligent Video Analytics
IVA license Intrusion, line crossing, counting line, loitering, enter, exit, tamper, object removed, tailgating, direction, stopped, appear, disappear, object left, logical rules.
Operational
3D digital noise reduction Smart DNR™ 3D Digital Noise Reduction
Auto gain control Auto
Day and night Auto day/night
Day (color)
Night (B/W)
De-fog Yes
Memory slot 4x Micro SD/SDHC/SDXC class 10 cards (cards not included)
Up to 1TB micro SD / FAT32
Mirror/flip Yes
Motion Detection Yes
Operational Notifications Alarm output activation
Email
FTP server
SD card recording
Privacy Zones 16 programmable privacy masks
Sharpness Yes
Shutter Mode Anti-Flicker
Auto
Manual
Slow Shutter
Shutter Speed 1/15 ~ 1/32000
Slow Shutter Speed Off
x10
x2
x3
x5
x6
x7.5
White Balance Yes
Wide Dynamic Range (WDR) True WDR 120dB
Network
Bitrate Control Multi-streaming CBR/VBR at H.264, H.265 (controllable frame rate and bandwidth)
IP IPv4
LAN 1000Base-T (1Gbps)
Network resolution 4. H.264: 2592x1944 2560x1440 1920x1080 704x576 704x480 640x480 640x360 352x288 352x240
4x MJPEG: 1920x1080, 1280x720, 800x600, 768x432, 704x576, 704x480, 640x480, 640x360, 352x288, 352x240
Network Web Viewer Google Chrome® browser
Linux® OS
Mac® OS
Microsoft Edge® browser
Mozilla Firefox® browser
Safari® browser
Windows OS
Protocol DDNS
DHCP
DNS
FTP
HTTP
HTTPs
ICMP
NTP
ONVIF
RTP (UDP/TCP)
RTSP
SMTP
SNMPv1/v2/v3 (MIB-2)
SSL
TCP/IP
UDP
Zeroconf (AutoIP)
Security 802.1x
Digest authentication (ID/PW)
HTTPS (TLS)
IP filtering
Stream Speed Up to 30fps at all resolutions
Streaming Capability Dual-stream at different rates and resolutions
Video Bitrate 100Kbps~10Mbps, multi-rate for preview and recording
Video Compression Type H.264
H.265
MJPEG
Video Management Software Any ONVIF conformant CMS
DW Spectrum®
ExacqVision Technologies
Milestone Systems
Environmental
Compliance CE  FCC  NDAA Comp  ONVIF  TAA Compliance  UL Listing
Environmental Operating Humidity 10-90% (non-condensing)
Environmental Operating Temperature -4°F ~ 122°F (-20°C ~ 50°C)
Mounting Accessories (Required/Optional) Required. Sold separately
Mechanical
Camera Dimensions (H X W X D) 8.26" x 3.61" (210 x 91.8 mm)
Camera Weight 4.18 lbs (1.9kg)
Housing Panoramic
Vandal Dome
Housing Color White
IK rating IK10 Rated
IP rating Weather Resistant (IP67)
Materials Aluminum die-casting
Polycarbonate Dome
Electrical
American wire gauge (AWG) 5M
Cable type #18
Power Consumption DC12V: max 28W, 2.33A
PoE: max 28W, 2.583A
Power Requirements High power PoE injector included
PoE
General
Warranty 5 Year Warranty
